Deadend Suspension Insulator
Deadend suspension insulator is engineered to anchor overhead conductors at line terminals, corners and dead end towers. It delivers reliable electrical insulation together with high tensile strength to sustain full conductor tension.
Description
Technical Parameters
Gaodian Technology Co., Ltd. is one of the most reliable manufacturers and suppliers of deadend suspension insulator in China. With abundant experience, we warmly welcome you to buy advanced deadend suspension insulator made in China here from our factory. We also accept customized orders.
Introduction
Deadend Suspension Insulator (also known as composite tension / strain insulator) is an important component for overhead high-voltage transmission and distribution networks. It has two main functions: electrically isolating live conductors, and mechanically bearing the tension load of power lines at dead-end positions, angle towers and section terminals.
Custom-built end fittings (clevis-tongue, ball-socket, Y-clevis, oval eye etc.) are available to match standard line hardware. Products comply with IEC 61109, ISO 9001 standards. Multiple voltage classes (10kV-220kV) and specified mechanical load ratings can be designed.
specification
| Product Type | Dead-End Suspension Insulator |
| Insulator Type | Composite / Polymer |
| Rated Voltage | 11–330 kV* |
| Mechanical Load | 40–210 kN* |
| Housing Material | HTV Silicone Rubber |
| Core Material | ECR |
| End Fittings | Steel / Forged Steel |
| Creepage Distance | Customized |
| Arcing Distance | Customized |
| Standard | IEC 61109 / IEC 62217* |
| Application | Dead-End / Tension / Terminal / Angle Structures |
| Customization | OEM & ODM Available |
Key Advantages
1. High Mechanical Strength
2. Excellent Pollution Resistance
3. Lightweight & Easy to Handle
4. Flexible End-Fitting Options
5. OEM & Custom Engineering
Typical Applications
Dead-End Structures
Used where overhead conductors are terminated and high mechanical tension needs to be transferred to the supporting structure.
Tension Sections
Suitable for line sections where conductors are under significant longitudinal mechanical tension.
Angle Structures
Used on overhead lines where the conductor changes direction and additional mechanical loads are present.
Terminal Structures
Suitable for the end sections of overhead distribution and transmission lines.
Medium-Voltage Distribution Networks
Applicable to overhead distribution systems such as 11kV, 15kV, 22kV and 33kV, depending on the product design.
Coastal & Polluted Environments
The silicone rubber housing provides good pollution performance in areas exposed to salt fog, dust and industrial contamination.
Product Construction
High-Strength FRP Core
Provides the main mechanical load-bearing capacity of the insulator.
HTV Silicone Rubber Housing
Provides electrical insulation, hydrophobicity and protection against outdoor environmental conditions.
Metal End Fittings
Transfer mechanical loads and provide a secure connection between the insulator, conductor and supporting hardware.
Customized Connection Design
End fittings can be manufactured according to customer drawings, samples or existing line hardware.
our manufacturing and testing facilities for insualtor
Our certificate
delivery and shipping
Q&A
Q: Where are Dead-End Suspension Insulators used?
A: They are commonly used at dead-end, terminal, angle and tension structures on overhead distribution and transmission lines.
Q: What is the difference between a suspension insulator and a dead-end insulator?
A: The main difference is the application and mechanical connection. Dead-end applications require the insulator and its fittings to withstand significant conductor tension. The end-fitting design is therefore especially important.
Q: Can you customize the metal fittings?
A: Yes. GAODIAN can develop customized end fittings according to customer drawings, samples or existing line hardware.
